6 series roof ventilator

Product Specification

We are upgrading our site, for technical information or product PDF’s call us on 1800 805 062

Previously known as:

Zephyr Series

See our product overview Download PDF

Airocle’s 6 Series stationary roof ventilators are ‘green’, economical, and sustainable high-performance natural extract ventilators

6 Series innovative engineered stationary roof heads are symmetrical with the system’s exterior wind deflectors and its gravity exhausters resulting in high-performance natural air extraction with no back draughts.

When wind passes at a high velocity outside, this symmetry creates a powerful suction force, whilst interior deflectors prevent the rush of air accelerating out of the ventilator from reversing.

Optimal performance of the 6 series in all weather conditions has been established during rigorous scientific testing and through their successful application in sites around the world.

Applications & Uses

The 6 Series roof ventilators are a heavy-duty yet environmentally-sustainable and economical natural ventilation solution suitable for industrial, commercial and community uses.

They are able to be fitted on slope, ridge, flat, or curved roofs offering optimum versatility to accommodate all architectural projects with a strong aesthetic.

Being storm-proof, water-tight, and are capable of withstanding up to 2 kpa of wind pressure without external guy wire, the 6 Series ventilators provide your building with full protection from the elements, while guaranteeing a pleasing design.

Key Benefits

  • Engineered design, which guarantees high performance and a strong aesthetic.
  • Using nature’s forces to extract air effectively, the innovative design of the 6 Series roof ventilators will provide optimum air extraction at a coefficient of discharge of 0.36.
  • Being low weight and highly versatile, the 6 Series vents can be easily fitted on most building structures.
  • Weather-proof construction providing a water-tight ventilation solution for any building.
  • Environmentally sustainable with limited energy use to run and maintain.

Installation & Options

Customisable in options of Colorbond, Zincalume, galvanised steel, aluminium or stainless steel, the Airocle 6 Series roof vents provide the perfect adaptable architectural ventilation solution for the future.

6 Series roof vents require roof bases, which are precision manufactured in 5 types to accommodate your specific roof profile.

The 6 Series roof ventilators can withstand up to 2kpa of wind pressure without any additional wires.

NB.  For ventilators and bases 600mm diameter and over, additional support between purlins is required. Base type and roof pitch must be specified. Extension flue pipes longer than 1000 mm above the roof line must be fitted with guy wires.

Options

  • Disc or butterfly dampers can be installed in the duct and are optional. Dampers are counterweighted or feature spring returns for normal opening operation.
  • Optional damper actuator equipment including electric motors/ pneumatic cylinders are available upon request.
  • Bird screens, which keep birds and insects from entering the ventilators, whist maintaining their water tightness, are also available as an optional extra.

Maintenance

Airocle’s ventilators use efficient design coupled with natural science.

Once installed, the system operates without running or maintenance costs.

This means 6 Series (previously Zephyr) gives long-term operational savings, for the building as well as the environment.

Here at Airocle, our vast experience enables us to advise on the most efficient design for your project.

Contact us for a no-obligation site survey and quote relating to either existing buildings or building plans for proposed buildings.
